Technical specifications
Technical specifications KSI
| KSI 7000 | KSI 12000 | KSI 16000 |
|---|---|---|
|
Recommended excavator weight: 35 – 55 t |
Recommended excavator weight: 50 – 80 t¹ | 80 – 120 t |
Recommended excavator weight: 75 – 120 [ 1 ] | 120 – 2000 t |
|
Rated hydraulic power: 130 kW |
Rated hydraulic power: 220 kW |
Rated hydraulic power: 300 kW |
|
Mixing width (A): 350 – 500 mm |
Mixing width (A): 450 – 650 mm |
Mixing width (A): 600 – 950 mm |
|
Width of gearbox (B): 4 | 5 | 6 | 7 mm |
Width of gearbox (B): 6 | 8 | 10 | 12 mm |
Width of gearbox (B): 6 | 8 | 10 | 12 | 14 | 16 mm |
|
Modular mixing depth (C): 1,000 m |
Modular mixing depth (C): 1,360 m |
Modular mixing depth (C): 1,630 m |
|
Recommended chain speed: 2,0 – 2,5 m/s |
Recommended chain speed: 2,0 – 2,5 m/s |
Recommended chain speed: 2,0 – 2,5 m/s |
|
Recommended oil flow at 150 bar: 300 – 400 l/min |
Recommended oil flow at 150 bar: 500 – 600 l/min |
Recommended oil flow at 150 bar: 650 – 825 l/min |
|
Max. oil flow: 400 l/min |
Max. oil flow: 650 l/min |
Max. oil flow: 850 l/min |
|
Maximum hydraulic pressure: 400 bar |
Maximum hydraulic pressure: 400 bar |
Maximum hydraulic pressure: 400 bar |
|
Max. permissible ground compressive strength 10 MPa |
Max. permissible ground compressive strength 10 MPa |
Max. permissible ground compressive strength 10 MPa |
|
SStandard mixing tool: Type DT 22/46/38/22 HC |
Standard mixing tool: Type DT 22/90/70/30 HQ |
Standard mixing tool: Type DT 22/90/70/30 HQ |
| KSI 7000 | KSI 12000 | KSI 16000 |
|---|---|---|
|
Weight at maximum cutting depth 4,500 kg |
Weight at maximum cutting depth: 12,500 kg |
Weight at maximum cutting depth: 19,500 kg |
|
Weight per meter extension: 400 kg |
Weight per meter extension: 800 kg |
Weight per meter extension: 1600 kg |
¹ Attachment only with special adaptor to boom and additional counterweight on excavator. Size of counterweight depends on excavator and should be agreed with excavator manufacturer.
Technical specifications KRD MIX
| KRD 120 MIX | KRD 150 MIX | KRD 165 MIX |
|---|---|---|
|
Recommended excavator weight: 25 – 40 t |
Recommended excavator weight: 30 – 40 |
Recommended excavator weight: 35 – 50 |
|
Rated power : 120 kW |
Rated power : 120 kW |
Rated power : 160 kW |
|
Max. mixing depth: 6 m |
Max. mixing depth: 6 m |
Max. mixing depth: 6 m |
|
Length of mixing cutter without extension (A): 1.070 mm |
Length of mixing cutter without extension (A): 1.070 mm |
Length of mixing cutter without extension (A): 1.070 mm |
|
Width of mixing head (B): 1,000 mm |
Width of mixing head (B): 1,000 mm |
Width of mixing head (B): 1,260 mm |
|
Diameter of mixing head (C): 730 mm |
Diameter of mixing head (C): 730 mm |
Diameter of mixing head (C): 720 mm |
|
Recommended rotation speed: 70 U/min |
Recommended rotation speed: 65 U/min |
Recommended rotation speed: 60 U/min |
|
Recommended oil flow: 250 – 330 l/min |
Recommended oil flow: 280 – 350 l/min |
Recommended oil flow: 300 – 390 l/min |
|
Max. oil flow at 10 bar: 350 l/min |
Max. oil flow at 10 bar: 350 l/min |
Max. oil flow at 10 bar: 400 l/min |
|
Max. operating hydraulic pressure: 400 bar |
Max. operating hydraulic pressure: 400 bar |
Max. operating hydraulic pressure: 400 bar |
|
Weight of mixing cutter without extension: 1.500 kg |
Weight of mixing cutter without extension: 1.500 kg |
Weight of mixing cutter without extension: 2.020 kg |
|
Number of mixing tools: 48 Stk. |
Number of mixing tools: 48 Stk. |
Number of mixing tools: 58 Stk. |
|
Standard mixing tool: Type DT 22/90/70/30 HQ |
Standard mixing tool: Type DT 22/90/70/30 HQ |
Standard mixing tool: Type DT 22/90/70/30 HQ |
| KRD 120 MIX | KRD 150 MIX | KRD 165 MIX |
|---|---|---|
|
Possible extensions (D)¹: 2 – 5 m |
Possible extensions (D)¹: 2 – 5 m |
Possible extensions (D)¹: 2 – 5 m |
|
Length of standard extension (D): 2 m |
Length of standard extension (D): 2 m |
Length of standard extension (D): 2 m |
¹ Verlängerung auf Anfrage.
Technische Daten KRX
| KRX 70 | KRX 110 | KRX 120 | KRX 130 | KRX 140 |
|---|---|---|---|---|
|
Recommended excavator weight: 15 – 25 t |
Recommended excavator weight: 20 – 35 |
Recommended excavator weight: 25 – 40 |
Recommended excavator weight: 25 – 40 |
Recommended excavator weight: 30 – 50 |
|
Rated power: 70 kW |
Rated power: 110 kW |
Rated power: 120 kW |
Rated power: 120 kW |
Rated power: 140 kW |
|
Length of drive unit: 830 mm |
Length of drive unit: 842 mm |
Length of drive unit: 842 mm |
Length of drive unit: 842 mm |
Length of drive unit: 875 mm |
|
Torque at 380 bar: 16.000 Nm |
Torque at 380 bar: 25.400 Nm |
Torque at 380 bar: 30.300 Nm |
Torque at 380 bar: 33.000 Nm |
Torque at 380 bar: 36.400 Nm |
|
Max. oil flow at 10 bar: 300 l/min |
Max. oil flow at 10 bar: 320 l/min |
Max. oil flow at 10 bar: 350 l/min |
Max. oil flow at 10 bar: 350 l/min |
Max. oil flow at 10 bar: 390 l/min |
|
Max. hydraulic pressure: 400 bar |
Max. hydraulic pressure: 400 bar |
Max. hydraulic pressure: 400 bar |
Max. hydraulic pressure: 400 bar |
Max. hydraulic pressure: 400 bar |
|
Weight without attachment: 520 kg |
Weight without attachment: 540 kg |
Weight without attachment: 540 kg |
Weight without attachment: 540 kg |
Weight without attachment: 900 kg |
|
Hex connection, standard 160 mm |
Hex connection, standard: 160 mm |
Hex connection, standard: 160 mm |
Hex connection, standard: 160 mm |
Hex connection, standard: 160 mm |
